Model: CC 12
DIMENSION: 96×96×50
PANEL CUTOUT: 92×92
DISPLAY:
Upper: 7-Segment 4-Digit 0.5” Red LED Display—Process Value
Lower: 7 Segment 4-Digit 0.4” Green LED Display – Set Value
INPUT: 1-5 Amp AC (RMS), 0-20 Amp (Factory Set)
CT SELECTION: 60/5A to 1000/5A through Direct CT/CT Selection
OUTPUT: 1 Relay (5A, 230V AC) / Relay Switch When Relay is Switched ON
POWER SUPPLY: 230V AC, 50Hz
INDICATION: Relay Status Indication
DIMENSION: 96×96×50
PANEL CUTOUT: 92×92
DISPLAY:
Upper: 7-Segment 4-Digit 0.5” Red LED Display—Process Value
Lower: 7 Segment 4-Digit 0.4” Green LED Display – Set Value
INPUT: 1-5 Amp AC (RMS), 0-20 Amp (Factory Set)
CT SELECTION: 60/5A to 1000/5A through Direct CT/CT Selection
OUTPUT: 1 Relay (5A, 230V AC) / Relay Switch When Relay is Switched ON
POWER SUPPLY: 230V AC, 50Hz
INDICATION: Relay Status Indication
