Model: ACS-100, ACS-200

ACS-100

DIMENSION: 40×65×85

POWER SUPPLY: 5VDC (White)

SCANNING DISTANCE: 8–10 mm

SWITCHING OUTPUT: Relay + Supply (–5V)

SWITCHING FREQUENCY: 1000 Hz

RETENTION: Non-Volatile Memory

CONNECTION:

RED WIRE: Supply (12V to 24V)

BLACK WIRE: Ground (0V)

GREEN WIRE: PNP (Control)

YELLOW WIRE: NPN (Output)

ACS-200

DIMENSION: 40×65×85

POWER SUPPLY: 24VDC

SCANNING DISTANCE: 4–6 mm (White/Red/Green)

SWITCHING OUTPUT: Relay + Supply (–5V)

SWITCHING FREQUENCY: 1000 Hz

RETENTION: Non-Volatile Memory
